TestProcess.Source.Ratio.AmplitudeModulation

A test process that sources an Amplitude Modulated (AM) on a specified Carrier Frequency with a specified modulation rate.

Required Parameters

  • Frequency – Frequency of the carrier signal
  • Power – Power of the carrier signal
  • Depth – Amplitude Modulation Depth
  • Rate – Modulation Frequency

Optional Parameters

  • Impedance – Input Impedance (50 Ohms assumed)
  • UUT.Input – Input Name of the UUT Connecting Point

Output Value & Uncertainty

    • Percent – %
